BLACK MAGIC Design DeckLink 4K Extreme Capture & Playback Card features two SDI inputs supporting 6G and 3G capability, assignable in the BLACK MAGIC Control Panel.
With all the latest firmware updates installed, you can ingest DCI 4K, 4:2:2, or UHD 4K, YUV, 4:2:2 by single-link 6G-SDI.
The second input shuts off in this setup. DCI 4K, 4:2:2 can also be ingested via the HDMI input with the latest firmware installed.
With 3G-SDI assigned, you can ingest single-link, 1080p, RGB, 4:4:4; and with HD-SDI assigned, you can ingest single-link 1080p, 4:2:2, or dual-link, 1080p, 4:4:4.
You can also use the SDI inputs for dual-channel 2D/3D stereoscopic workflows.
The remaining connections include two SDI outputs, an HDMI output, and Component, Composite, S-Video, XLR, RS-422, and genlock on an included breakout cable.
The card also features an internal SD/HD keyer and broadcast-quality up/down/cross conversion.
DeckLink 4K Extreme is compatible with Mac, Windows, and Linux based workstations and media servers and supports a comprehensive list of software (please see below).
- Key Features
- – PCIe I/O card compatible with Mac, Windows, and Linux based workstations and servers
– DCI 4K, 4:2:2, or UHD 4K, YUV, 4:2:2 by single-link 6G-SDI
– DCI 4K, 4:2:2 by HDMI
– 1080p, RGB, 4:4:4 by single-link 3G-SDI
– 1080P, 4:2:2 by single-link HD-SDI
– 108OP, 4:4:4 by dual-link HD-SDI
– Dual-channel 2D/3D stereoscopic by SDI
– Component, Composite, S-Video, XLR, RS-422, and genlock on an included breakout cable
– Internal SD/HD keyer
– Broadcast-quality up/down/cross conversion
